PIR/microwave/Bluetooth/IoT system for optional, Multiple installation methods, energy saving, darkSky standard design for South America market, individual battery pack, adjustable bracket...
INQUIRY NOWAll in one solar street light DarkSky standard design for South America market
· PIR/microwave/Bluetooth/IoT system for optional.
· Multiple installation methods.
· Energy saving, individual battery pack.
· Adjustable bracket.
· DarkSky standard design for South America MARKET.
Feature:
· Special and integrated shell lens to make sure there is no light from the front/rear/left/right view of the light, Darsky standard design specially for South America market.
· Streamline and Integrated design by aviation grade aluminum alloy body, anti-corrosion surface treatment for >10years lifespan, patented product.
· DIY module structure, simply divided by 3parts, solar panel, led with lamp case and energy pack.
· Amazing lighting effect with high brightness chips. Achieve more than 170lm/w.
· Bluetooth function, just use mobile to control the lamp and set working parameter.
· PIR/microwave sensor for optional.
· Internet of things is also optional function, make all lamp work smart and intelligent control .
· Simple and fool proof installation, just put the bracket onto pole and fasten the screws.
Model | YF-EIF-DK-40 | YF-EIF-DK-60 | YF-EIF-DK-100 |
LED Street Light Power | 20W(1 LED Module) | 30W(1 LED Module) | 40W(2 LED Module) |
PV Model | 70W | 90W | 120W |
Lumen Flux | 4500lm | 6600lm | 10000lm |
LED Chip | 32PCS 5050 LED Bridgelux | 64PCS 5050 LED Bridgelux | 90PCS 5050 LED Bridgelux |
Light Distribution Type | Type II | Type II | Type II |
Viewing Angle | 70°*140° | 70°*140° | 70°*140° |
CRI | >80 | >80 | >80 |
Life time | >10 years | >10 years | >10 years |
Battery Tape | LiFePO4 Battery | LiFePO4 Battery | LiFePO4 Battery |
Battery Capacity | 384WH | 512WH | 896WH |
Battery life time | (5-8 years) | (5-8 years) | (5-8 years) |
MPPT Change Controller | Including Wireless Communucation Module | Including Wireless Communucation Module | Including Wireless Communucation Module |
Working model | Motion Sensor/time | Motion Sensor/time | Motion Sensor/time |
Charging Time(STC) | 6-8 Hours(With STC) | 6-8 Hours(With STC) | 6-8 Hours(With STC) |
Certificate | CE、ROSH、IP65 | CE、ROSH、IP65 | CE、ROSH、IP65 |
Storage Temperature | 0℃~45℃ | 0℃~45℃ | 0℃~45℃ |
Protection Grade | IP65 | IP65 | IP65 |
Dimension Size(mm) | L1010*W358*H82mm | L1310*W235*H98mm | L1630*W235*H98mm |
Installstion Height | 5-7M | 6-8M | 7-10M |
Installation Diameter | ≤80mm | ≤80mm | ≤80mm |
Warranry | 3 years | 3 years | 3 years |
FAQ:
Q: how about your company history?
A: our company original start from 2005 to supply components and accessory for led lighting company, then move to & only focus solar street lighting production since 2010, we have 10 years of solid business experience.
Q: What is your main product?
A: we used to manufacture various type of led outdoor light, but now we just focus on solar lighting, grid power light and some off-grid home system.
Q: What is your business service?
A: all our product is self-developed patent product, we also provide ODM/OEM service, semi knock down to help customer lower the tariff and fulfill local content.
Q: What is your core competence & flexibility?
A: we have stronger and experienced R & D, quality control, production and international sales team. Offer quick response and action to customer inquiry or characteristic requirement. Our product is module design, there is great flexibility to extend the specification to meet customer expectation.
Q: are your manufacturer? how about your production capacity and delivery lead time?
A: yes, we have more than 3000squre electronic parts production, final assembly and testing workshop, and another 8000square meters for metal part diecast, powder coating, and mechanical process. We also keep minimum inventory for common parts, so our lead time, sample: 3 days, small batch: 1-week, bulk order: 2-4weeks.
Q: How many years of warranty offered? How is lifespan of your product
A: all our product line offers 3 years of warranty base on terms and conditions, and lifespan is 6-8 years depends on working environment.
Q: do you help installation, maintenance and commissioning?
A: we provide good technical support, training or even on-site commissioning upon customer request. Very good one stop turnkey solution & service.
