25.6V 24V Solar street light Battery pack, energy pack, solar off grid system, IP65, bluetooth app...
INQUIRY NOW
· The battery adopts power lithium iron phosphate battery, the cycle life is more than 3000 times, and it can be used for 5-8 years;
· MPPT controller, faster charging and better protection function;
· LED adopts patented adaptive function, only need to set power, automatically adapt to 5-17 strings of LED lamp beads
· All aluminum alloy shell, anodized surface, anti-corrosion, reliable structure, convenient installation;
· Bluetooth APP management, human-computer interaction is more intuitive, and the operation is convenient;
| Model No. | YF-BP-802 | YF-BP-803 | YF-BP-804 | YF-BP-805 | |
| Battery type | LiFePO4 | ||||
| Battery capacity | 1280WH | 1536WH | 2304WH | 3072WH | |
| Rated power | 100W Max | 160W Max | 200W Max | ||
| Suggest LED power Max | 80W | 100W | 150W | 200W | |
| LED volts | 30V—54V | ||||
| MPPT volts | 30V≤Vmp≤60V | 30V≤Vmp≤70V | |||
| Charge model | MPPT | ||||
| Charge current | 10A | 15A | 20A | ||
| Solar panel input volts Max | Vmp≤55V | Vmp≤85V | |||
| Solar panel power | Pm≤260W | Pm≤390W | Pm≤520W | ||
| Communication model | Bluetooth app | ||||
| Working model | 12hrs (can be adjusted) | ||||
| N.W（kg） | 13.5 | / | / | / | / |
| G.W（kg） | 14.5 | / | / | / | / |
| Demension（mm） | 325*340*85 | 415*340*85 | 485*340*85 | 580*260*85 | 690*240*110 |
| Ctn size（mm） | 360*380*130 | 460*380*130 | 530*380*130 | 630*300*130 | 740*280*150 |
DIY off grid solar system solar energy power packs 3KV for solar street lights system
· Solar street light Battery pack, 24V, 25.6V
· Energy pack,
· Solar off grid system,
· IP65,
· Bluetooth app
DIY off grid solar system solar energy power packs 3KV for solar street lights system
· LiFePO4 battery pack solar system
